| Model | FCOSDR - 1000DC | FCOSDR-1500DC | FCOSDR-2000DC | FCOSDR-3000DC |
| Drilling Depth (4-1/2" Drill Pipe), ft | 13,000 | 16,000 | 23,000 | 30,000 |
| Static Hook Load, lbs | 500,000 | 750,000 | 1,000,000 | 1,500,000 |
| Number of Lines Stung to The Traveling Block | 10 | 12 | 12 | 14 |
| Diameter of Drilling Line, in | 1-1/4" | 1-3/8" | 1-1/2" | 1-3/4" |
| Drawworks Rated Power, HP | 1,000 | 1,500 | 2,000 | 3,000 |
| Main Brake | Hydraulic Disc Brake | Hydraulic Disc Brake | Hydraulic Disc Brake | Hydraulic Disc Brake |
| Auxiliary Brake | Eddy Current Brake | Eddy Current Brake | Eddy Current Brake | Eddy Current Brake |
| Mast Type | Cantilever/Bootstrap | Cantilever | Cantilever | Cantilever |
| Mast Height, ft | 141 | 148 | 148 | 158 |
| Substructure Type | Box-on-Box/ Slingshot | Box-on-Box/ Slingshot / Swing-lift | Slingshot / Swing-lift | Swing-lift |
| Substructure Height, ft | 25 | 29.5 | 34.5 | 40 |
| Clear Height Under Rotary Beam, ft | 20 | 25 | 29.5 | 33 |
| Rotary Table | 27-1/2" | 37-1/2" | 37-1/2" | 49-1/2" |
| Hook Block, lbs | 500,000 | 750,000 | 1,000,000 | 1,500,000 |
| Swivel, lbs | 500,000 | 750,000 | 1,000,000 | 1,500,000 |
| Mud Pumps | F-1000 x 2 | F-1000 x 2 | F-1000 x 3 | F-1000 x 3 |
